Galvanized 20 Ton HD Equipment Float Trailer w/ Air Brakes

LIFETIME WARRANTY* MADE IN CANADA

Float large equipment with ease - Miska's Air Brake Tag-Along Float Trailers are fully customizable to suit whatever you need to haul!

SAVE $3,735

Factory Direct Pricing From Only

$40,460

Finance from $399/bi-weekly

Competitor Dealer Retail Price: $44,195

Start Your Quote Apply for Financing
Thank you for selecting our Factory Direct Galvanized 20 Ton HD Equipment Float Trailer w/ Air Brakes

Now, you have two simple options:

  1. Choose an in-stock value package below: These packages are designed to meet the needs of most of our customers.
  2. Customize Your Trailer with Additional Options: Select from a range of premium options to factory order a trailer to your exact specifications. Only pay for the features you need—without any dealer markup.

Once you've made your selection, click “Request Quote”, and one of our expert Sales Team members will reach out to you within 24 hours.

Select Your Size

Specification Details
Size 102'' x 20' + 5' beavertail
GVWR 40000 lbs (18144 kg)
Empty Weight 9860 lbs (4472 kg)
Payload 30140 lbs (13671 kg)
Width 102 in (8.5 ft)
Length 25 ft
Deck Height 37 in (3.08 ft)
Warranty Industry Leading Lifetime Warranty*
Electrical Plug 7 Pin Round
Jack Holland Dual 25K
Safety Chains 1/2" Safety Chains, Grade 70
Coupler 3" Adjustable 60K Pintle
Axle (2) 20,000 Oil Bath Axles
Brakes 2 Air axle brakes-(1 is ABS axle)
Suspension Spring w 49" Spread
Ramp Ladder
Frame 14" Beam (26#)
Cross Members every 16'' Pierced Frame
Floor 2" Hardwood
Tires ST235/75R17.5 on Dual Wheel
Tie Downs 16-1'' d rings
Toolbox optional
Lights LED Rubber Mounted Stop, Turn & Clearance

Swipe to scroll

Feature Base Model Galvanized 20' + 5' Excavator Model Galvanized 24' + 6' Paver Model
2" x 8" Rough Oak Deck
Crash Bar
LED Lights
Sealed Wiring Harness
In-Tongue Toolbox
D-Ring Tie Downs
Spring Assist Ramps
Air Ramps w/ Self Cleaning Beavertail
96" Wood Top Air Paver Ramps w/ Wood Top Beavertail
Competitor Dealer Retail Price $44,195 $47,395 $50,495
Miska Trailer Factory Direct Price $40,460 $43,460 $46,240
Finance From
$399 /bi-weekly
$429 /bi-weekly
$456 /bi-weekly


Axle Type
Custom Options

Includes (5) Ratchet Binders & (5) 3/8" Chain

Includes (4) Ratchet Binders & (4) 3/8" Chain

For mounting sliding ratchet tie downs

Extra Length

Available in 1' Increments - please specify in Special Requests when submitting your quote request

Jack
Pockets
Ramp Style
Sides
Spare Tire Choice
Tires
Toolbox
Print

PRE-OWNED TRAILERS

The following trailers are in stock and ready for immediate pickup.

2024 Miska 5 Ton Lowbed Equipment Trailer

2024 Miska 5 Ton Lowbed Equipment Trailer

$5,995

VIEW TRAILER
2018 T-Man 15 Ton Equipment Float Trailer

2018 T-Man 15 Ton Equipment Float Trailer

$14,995

VIEW TRAILER

MORE ABOUT MISKA'S DECKOVER EQUIPMENT FLOATS

Miska’s Canadian-Made Flatbed Equipment Float Trailers are built to handle the heaviest loads with ease. Designed for contractors, construction crews, and equipment haulers, these trailers deliver rugged durability, superior strength, and smooth towing—job after job.

*Certain exceptions, limitations and exclusions apply to Lifetime Warranty. Please refer to full warranty policy for complete details. Miska Trailers is not responsible for errors and mistakes that occur in ads, specifications, or prices. Prices, specifications, and options are subject to change without notice.
